Disc toothed crusher
A feed processing crusher is used for crushing feed during the feed processing. It can be used in conjunction with a hammer mill to increase production capacity, improve efficiency and save energy consumption.
MOQ: 1
- Overview
- Recommended Products
Product Overview
A feed processing crusher is used for crushing feed during the feed processing. It can be used in conjunction with a hammer mill to increase production capacity, improve efficiency and save energy consumption.
Specifications and Parameters
| MODEL | JFCDFS30X66 | JFCDFS20X66 | JFCDFS20X48 | ||
| POWER(KW) | 30X2 | 22X2 | 18.5X2 | 15X2 | 11X2 |
| 4-MESH SIEVE OUTPUT(T/H) | 60.0 | 43.0 | 37.0 | 28.0 | 22.0 |
| 6-MESH SIEVE OUTPUT(T/H) | 40.0 | 30.0 | 24.5 | 19.0 | 14.5 |
| 10-MESH SIEVE OUTPUT(T/H) | 18.0 | 12.5 | 11.0 | 8.2 | 6.5 |
Product Details Description
1) Shear crushing is carried out through the relative meshing of several sets of high-speed rotating discs.
2) The fine teeth are sealed on the crushing disc. The finer the teeth, the finer the degree.
3) The disc with differential rotation can increase the shearing of the materials.
